STB
Electronic Movement Time Lock
STB Electronic Movement Timelocks offers independent time-based access control that supersedes key & combination access. STB Electronic Movement are based on the proven functionality of STB’s Mechanical movements. It offers increased ease of use, functionality and value. Three levels of product allow STB to respond and exceed the requirements of the Secure Container Industry.
Video ManualFeatures
- Swiss made electro-mechanical movement
- Programmable up to 199 hours (option 999h)
- Accuracy +/-1 sec./day (based on one opening per day)
- Battery life up to 4 years (based on one opening per day)
- Long-life gold plated contacts
- Easy-to-read Liquid crystal display
- Standard Time Lock footprint allowing easy retrofit into any manufacturers Timelock Case
- Maintenance free
- Optional exterior AA Battery power pack
- By Pass option with keypad
- UL certified
| 114E-1010 | 114E-1010.BP | 134N | |
| Order Number | 10.0006 | 10.0006.BP | 10.0004 |
| Specification | 199 Hour Reset Movement | 199 Hour Reset Movement
By Pass function |
999 Hour Reset Movement
Weekly pre-programable |
By adding the desired movement order number will, complete the part number configuration
Example:
1600 case with a 104-1704 Movement will give the Order Number 1600/104-1704
